LTMG best price warehouse 3 ton diesel forklift with triplex mast

Brand Name : LTMG

Model Number : FD30

Certification : CE, ISO, EURO, EPA

Place of Origin : China

MOQ : 1 unit

Price : USD 6900-11000/unit

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 500 units per month

Delivery Time : 25 days

Packaging Details : Nude packing, fix in container

Fork size : 1070X125X45mm

lifting height : 3000mm~6000mm

Load Center : 500mm

Free lift : 150mm

Wheelbase : 1700mm

Warranty : one year or 2000 working hours

Color : Customer Demanded

Contact Now



LTMG best price warehouse 3 ton diesel forklift with triplex mast



Feature:

1. Dual filter protect engine effectively than normal single filter.

2.According to dusty working conditon,air prefilter is optional for customer use.

3.Optimize counter weight to enlarge ventilation,heat dispersion is substantial improved.


4.Toyota-copy half enclosed seat can be adjusted on tandem position and backrest angle,also with seat belt,


5.Reinforced steering axle ensure higher rigidity and durability.



Specification:

Features 1 Manufacturer     LTMG
2 Model
Manual shift T/M FD30
3 Load capacity   kg 3000
4 Load center   mm 500
5 Power unit     Diesel
6 Operator type     Driver/seat
7 Tire type     Pneumatic
8 Wheel Front/rear   2/2
Dimension 9 Max. lifting height   mm 3000
10 Free lift   mm 150
11 Fork size L*W*T mm 1070*125*45
12 Tilt range Mast forward/backward deg 6/12
13 Overall length(without fork)   mm 2705
14 Total width   mm 1225
15 Mast height (fork lowering)   mm 2075
16 Overall height fork raised With backrest mm 4250
17 Height to head guard   mm 2140
18 Turning raduis(outside)   mm 2445
19 Front face of fork to front axle   mm 480
20 Min. right angle stacking aisle without load length&clearence mm 2925
Performance 21 Speed Max Travelling full/no load km/h 18/19.5
22 Lifting full/no load mm/s 450/500
23 Lowering full/no load mm/s 450/450
24 Max.drawbar pull Power shift T/M full/no load kg 1500/1000
Manual shift T/M full/no load kg 1550/1000
25 Gradeability at 1.6km/h Power shift T/M full/no load % 18/20
Manual shift T/M full/no load % 18/20
Weight 26 Truck weight   kg 4380
27 Weight distribution Full load front/rear kg 6490/890
28 No load front/rear kg 1670/2700
Frame 29 Tires Number front/rear 2/2
30 Model front axle 28x9-15-12PR
31 rear axle 6.50-10-10PR
32 Wheelbase   mm 1700
33 Tread Front/rear mm 1000/970
34 Ground clearence At lowest point(mast) mm 120
Frame mm 135
35 Brake Service brake   Hydraulic-foot pedal
Parking brake   Mechanical-hand lever
Engine 36 Battery Voltage/capacity V/AH 12/80
37 Engine Model   ISUZU C240
Rated power kw/rpm 34.3/2500
Rated torque N.m/rpm 138/1800
Number of cylinders   4
Placement L 2.369
Fuel tank capacity L 70
38 Transmission Speed forward/backward Power shift T/M Manual shift T/M 1-1 power shift T/M 2-2 manual shift T/M
39 Operating pressure Hydraulic system pressure kg/cm² 180



LTMG best price warehouse 3 ton diesel forklift with triplex mast



LTMG best price warehouse 3 ton diesel forklift with triplex mast



After-sale service:

Nowadays we have been sell more than 100 countries. LTMG Machinery is committed to offer not only products with high quality and performance and competitive price, but also in-time delivery and comprehensive after-services.
All the products of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.During the warranty period, if there is any part broken because of quality problem (except easy-damaged parts), the defective parts will be repaired or replaced free of charges.
Detail clauses and policies please see to our website and product’s quality certificate.
